Star SP700 POS nyomtató Blokk-Nyomtató, soros grafi

9-tűs mátrix; 4.7 - 8.9 sor/sec; Soros; 76 / 69.5 / 58 mm; egyszerű Drop-in&Print papírbetöltés, két színű nyomtatás, álló helyzetben/falra szerelve is használható, szennyeződésnek/folyadéknak ellenálló kialakítás, automatikus Logo és grafika nyomtatás, grafitszürke színben


Termék weboldala


SP700 SERIES SPECIFICATIONS
Print Method 9 Pin Serial Impact Dot Matrix

Printer Versions:
SP712 Tear Bar Mono and Red / Black Model
SP742 Autocutter Mono and Red / Black Model (full or partial cut)
SP712 / 742 with rewind Tear Bar and Autocutter Rewind Models

Interface Versions RS232 / Parallel / USB 2.0 / Without Interface
Interface Options Ethernet / WiFi
Print Speed Capable of printing 13 x 20 line receipts per minute from
4.7 to 8.9 lps depending on number of columns
Paper Feed Speed Approx. 5.6 inches per second (@ continuous feed)
Print direction Bi-Directional, Logic Seeking

Print font:
Character Matrix 7 x 9 (Half dot) / 5 x 9
Column capacity 42 / 35
Character Size (mm) 1.2 (W) x 2.42 (H) / 1.5 (W) x 2.42 (H)
Character Set 95 Alphanumeric, 32 International
Code Pages 40
Character Per Inch (CPI) 16.9 / 14.1
Paper Loading Drop-In and Print, Easy Load with see-through cover

Paper Handling:
Width with guide included 76mm (default), 69.5mm, 58mm (+/- 0.5) x 85mm diameter
Thickness 1 ply 0.06 ~ 0.085mm
Copy Capability 2 ply Original + 1, 0.05 ~ 0.08 / piece, total less 0.14
Copy Capability 3 ply Original + 2, 0.05 ~ 0.08 / piece, total less 0.20
Wall Mount Facility Available on all models (up to 2 part paper)
Paper Sensors Paper End (Near End Sensor option - factory fit)

Ribbon Life:
RC700B 3 million characters
RC700BR Black 1.5 million characters / Red 0.75 million characters
Data Buffer 8 Kbyte
Program ROM Flash Memory (16Mbit), NV bit image 256 Kbyte
Emulation Star Mode and ESC/POS™
Power Supply INTERNAL Power Supply with power cable included
D.K.D. Function 2 Drivers
Reliability MCBF 22 Million Lines

Overall Dimensions
160 (W) x 245 (D) x 152 (H) mm
Weight
SP712: 2.96Kg, SP742: 3.18Kg, SP712R: 3.43Kg, SP742R: 3.65Kg
EMI Standard
VCCI Class A, FCC Class A, CE
Safety Standard
UL, C-UL, TÜV, CB, EN60950
Options
Buzzer, Wall mount / vertical use kit
